ADA Compliant Bathroom Vanity

Posted byDavid L. Traut, CAPS on Wed, Jan 15, 2020 @ 12:01 PM

    Traditionally bathroom vanities were constructed so the finished cabinet top was 30” AFF (above finished floor). This meant that taller people had to bend over and stand away from the sink in order to use it. This puts added stress on the lower back and legs diminishing the comfort factor. Typically bathroom vanities are 21" deep and approximately 29" tall. The depth is not a problem but most folks would prefer a universal design height of 34". Universally, sinks shouldn't be mounted higher than 34 inches from the floor to the top of the cabinet top for an under mount or drop in model. The sinks should not exceed six inches in depth and should be installed within three inches from the front of the overhanging cabinet top edge. The ADA vanity cabinet or even a simple wall hung sink should have a knee clearance below of 27 inches high and be at a minimum 32 inches wide by 11-25 inches deep. The choice of sink styles depends on the personal preference of the user. Be sure the lavatory controls are easily controlled with lever or paddle handles and are capable of being operated with one hand and not requiring tight grasping, pinching, or pinching of the wrist. Knobs, discs, or ball type handles can be hard to operate by anyone with soapy hands and more so by someone having an arthritic condition or other ailments. The closer the sink valves can be located toward the front of the sink the better. This can be accomplished by following the curved outline of the sink.

ADA compliant vanity in Austin



     There are basically two styles of ADA vanities that comply with an unobstructed roll under area below the sink.  This capability has everything to do with both the water supply lines and the main waste line connecting the sink.  There must be provisions made to protect the user from being scalded when coming into contact with any one of the plumbing pipes serving the sink.  These connecting pipes may become heated merely by the water passing through them creating a problem of scalding the user especially if they are unable of feeling sensations.  The open type model should always receive both waste and supply insulating jackets applied directly to the pipes providing protection for the wheelchair user.  The closed model concealing the pipes will be equipped with a removable face or panel board covering the pipes.  This pipe concealing panel must be installed at the correct angle.  This allows for the needed unobstructed legroom required for the  user.  The vanity can extend beyond the sink but the area containing the sink is required to have this roll under capability which is 27" tall and 32" wide.   This section of the vanity top must not be any taller than 34 inches above the finished floor with the sufficient lower clearance mentioned above.  Clear unobstructed reach distances around the counter top area must be observed at 24 inches.  Any motion controlled sensors integrated into the various dispensing devices and/or plumbing fixtures throughout the bathroom present a true hands free benefit to all the bathroom users.  If these aren't in the budget then at least wrist handles used for controlling the faucet can be incorporated into the design of the vanity.  Bathroom vanities with 34" universal height cabinet tops and open knee spaces are taking over the marketplace.  These new residential vanities do not need to look institutional.  They can be designed like any other piece of fine furniture.



ADA Compliant Vanity In Austin



Recommended Clear Dimensions And Requirements


     Sinks shouldn't be mounted higher than 34 inches from the floor to the top of the cabinet top for an under mount or drop in model.  The sinks should not exceed six inches in depth and should be installed within three inches from the front of the overhanging cabinet top edge.  A rear drain is recommended to have the proper clearance when rolling under the vanity.  The ADA vanity cabinet or even a simple wall hung sink should have a knee clearance below of 27 inches high and be at a minimum 30 inches wide by 11-25 inches deep.  A 9" high clear kick area (by 6" deep) at the floor should be maintained for a full height cabinet and be approximately ten inches deep according to the cabinet depth. Remember twenty four inches is the maximum reach distance while sitting in a wheelchair.  Be sure the lavatory controls fall within this range and are easily controlled being operated with one hand and not requiring tight grasping, pinching, or pinching of the wrist.

ADA Bathroom In Austin



Clear Floor Space


     To assure a clear floor space the lavatory must be installed at 24" from any side wall measuring from the center of the sink.  The distance from one sink to another if using a double lavatory layout should be at least 30" center to center.  In the case of wall hung freestanding sinks the minimum distance between them should be 4" between the sink edges.

ADA vanity in Austin

     A clear floor space of 30 by 48 inches must be provided to access all bathroom fixtures and these areas can overlap one another.  The adjoining and overlapping wheelchair turning space should be an unobstructed sixty inches in diameter.  A wheelchair turning space could utilize a T-shaped space considering a sixty inch square having two 12"x 24" areas removed from each corner of the square from the same side. This will be a 36" wide base with two 36" wide arms.  T-shaped wheelchair turning spaces can include on one arm.  In this case the clear width at the cabinet should be 36" to use the space as part of the T-turn.

ADA Bathroom Cabinets

     Let's face it, accessible homes are needed by all of us at some time in our lives.  This is true whether it's for ourselves, a family member, or a guest.  The need is certainly not driven by age but is a result of life's experience.  Any family living with disability among any of the generations within it's group can always benefit from additional accessibility.   This will in turn increase safety and independence for all involved as they go through life.

     Aging in place home modifications are available through T-Square Company. We are a certified aging in place (CAPS) specialist.  Each design/build situation will be customized to fit your personal needs. Call 512-444-0097 today to begin the accessible second chapter of your life while remaining safe and secure in your existing home. CAPS #1636580

Certified Aging In Place Specialist

Tags: disability remodeling, handicap access bathroom remodel, disability access contractor, accessible home remodeling for disabilities, ADA vanity in Austin, roll under vanity, what is an ADA compliant bathroom, universal design/build contractor, Austin home remodeling for disabled, accessible home modifications, wheelchair accessible bathroom, handicap bathroom design, handicap bathroom requirements, handicap bathroom sink, handicap bathroom vanity, wheelchair access, handicap bathroom contractor in Austin, accessible home builder in Austin, wheelchair accessible homes, special needs contractor, home renovations for disability in Austin, disability remodeling contractor in Austin, what is the height of a handicap vanity?, disability renovation services in a, disability renovation services in Austin Texas, ADA Compliant Bathroom Vanity

What Is The Height Of A Handicap Vanity?

Posted byDavid L. Traut, CAPS on Thu, Dec 12, 2019 @ 15:12 PM

     ADA guidelines state that accessible sinks shouldn't be mounted higher than 34 inches above the floor for adults. For children, the sink should be set at 29 inches maximum above the finished floor. Both these heights are dependent on the individual using the sink and are truly a set of guidelines. Adults should have a knee clearance of 27 inches high by 30 inches of width with 11-25 inches deep. For children or smaller adults, a knee clearance of 24 inches above the floor is recommended. All sinks for the handicapped user should have no more than a 6 1/2 inch depth.There should also be a clear associated floor space for approach in front of the vanity which measures 30 by 48 inches. This clear space is needed to approach all bathroom fixtures and the clear spaces can overlap within the bathroom design. To assure a clear floor space the lavatory must be installed at 24" from any side wall measuring from the center line of the sink. The distance from one sink to another if using a double lavatory layout should be at least 30" center to center. In the case of wall hung freestanding sinks the minimum distance between them should be 4" between the sink edges. A clear 24 inch reach distance must be observed to help assist a seated person.

ADA Vanity In Austin

     There is no one set of dimensions which works for everyone with special needs since everyone is different.   Bathroom cabinets in Austin vary by style and usability needs.  There are basically two styles of ADA bathroom vanities that comply with an unobstructed 27" tall roll under area below the sink.  ADA sinks with a rear drain location provide for better plumbing drain hook ups.  This modification has everything to do with both the water supply lines and the waste line connecting the sink.  There must be provisions made to protect the user from being scalded when coming into contact with any one of the plumbing pipes serving the sink.  These connecting pipes may become heated merely by the water passing through them creating the problem.  The open type model should always receive both waste and supply insulating jackets applied directly to the pipes providing protection for the wheelchair user.  The closed model concealing the pipes will be equipped with a removable face or face board covering the pipes.  This pipe concealing panel must be installed at the correct wheelchair user clearance angle.  This allows for the needed unobstructed legroom required for the  user.  The vanity can extend beyond the sink but the area containing the sink is required to have this roll under capability.  This section of the vanity top must not be any taller than 34 inches above the finished floor with sufficient lower leg clearance.  Clear unobstructed reach distances around the counter top area must be observed.  Any motion controlled sensors integrated into the various dispensing devices and/or plumbing fixtures throughout the restroom present a true hands free benefit to all the restroom users.  If these aren't in the budget then at least wrist handles used for controlling the faucet can be incorporated into the design of the vanity.  Furthermore, automatic flush valves should be used on all toilets and urinals that provide for hands free use.

ADA Bathroom Cabinets

     Finding a disability contractor familiar with the guidelines of Elder construction and accessibility for people with special needs can be quite difficult. Be sure to check out the credentials of any potential bidders you contact.  Also be sure they understand that the alterations you are seeking are for wheelchair accessible home remodeling and modifications.  Furthermore be sure this person knows and practices both the federal and most importantly your state's requirements before entering into any contract. We offer complete handicap accessible floor plans generated around our individual clients.

     Aging in place home modifications are available through T-Square Company. We are a certified aging in place (CAPS) specialist.  Each design/build situation will be customized to fit your personal needs. Call 512-444-0097 today to begin the accessible second chapter of your life while remaining safe and secure in your existing home. CAPS #1636580

     Let's face it, accessible homes are needed by all of us at some time in our lives.  This is true whether it's for ourselves, a family member, or a guest.  The need is certainly not driven by age but is a result of life's experience.  Any family living with disability among any of the generations within it's group can always benefit from additional accessibility.   This will in turn increase safety and independence for all involved as they go through life.

Increase Your Accessibility

Tags: remodeling for elders in Austin, disability and special needs contractor Austin, Austin disability contractors for special needs, handicap remodeling, disability remodeling, handicap access bathroom remodel, handicap bathroom remodel, disability access contractor, veterans home remodeling in Austin, Texas, ADA vanity in Austin, ADA vanity height, roll under vanity, specialty construction in Austin, home access in Austin, bathroom remodel contractor, home accessibility, accessible design, wheelchair accessible housing, accessible housing, handicap accessible housing, handicap accessible house plans, accessible homes in austin, Austin home remodeling for disabled, accessibility home modifications, accessible home modifications, wheelchair accessible bathroom, handicap bathroom design, handicap bathroom requirements, handicap bathroom sink, handicap bathroom vanity, modifying your home for a disabled child, handicap bathroom contractor in Austin, accessible home builder in Austin, wheelchair accessible homes, special needs contractor, home renovations for disability in Austin, disability remodeling contractor in Austin, what is the height of a handicap vanity?

Universal Home Design In Austin

Posted byDavid L. Traut, CAPS on Tue, Oct 29, 2019 @ 15:10 PM

     It appears that after so long a time of blogging, soap box deliveries, and conversations with my customers concerning the importance of Universal Design in the future of our home building industry others have listened and are in agreement. I was humbled to find this article published in the Austin American Statesman and take pride in the fact that people are beginning to see the importance of this very forward thinking design concept.  May this article help to propel the needed universal building movement forward.

     Universal design ideas do not strictly deal with accessibility or aging in place design and does not implement precise ADA standards but it does offer flexibility to add accessories now and later to those planning ahead or to the end user. It also provides for a wide range of human performance characteristics for the way people use spaces within their homes including well integrated usability features. These adaptations have a broad market appeal to everyone for achieving ease of use, safety, and convenience accommodating a certain reality. The reality is that all people exist along a continuum of human performance as per their personal traits and characteristics regardless of their age. A universal approach to design takes into account that everyone has varying degrees of ability and disability rather than someone is either fully-functional or disabled. A universal design build project is appealing to all users.When correctly applied,any area of the home will be accented universally with stylish function and will be virtually invisible.

     Aging in place home modifications are available through T-Square Company in Austin, Texas. Each universal design/build project will be customized to fit any and all homeowners personal needs. Call 512-444-0097 today to begin to prepare for the accessible second chapter of your life while remaining safe and secure in your existing home. T-Square Company will design and build you an adapted living environment completely customized toward your abilities. Whether your project concerns home modifications, an accessible addition or wing, or new construction we can help you increase your accessibility. We have over three decades of building and remodeling experience practicing as a disability contractor for people with special needs . We want to help our clients be as self sufficient and independent as possible by offering handicap accessible floor plans. Let us show you how to increase the safety and accessibility within your personal living environment.

CAPS 1636580



Accessible Homes Of Austin




The trend toward 'universal design' in homes
Tuesday, Jan 15, 2019 @ 3:57pm
By David Wilfong

universal home design in Austin

Simple adjustments like a sideways opening oven can make life a lot easier for a person in a wheelchair. | Jofre Essley / Flickr
For many years disabled people faced challenges at every corner of public life. Stairs, rough ground, or even just reaching objects on a shelf created obstacles at inopportune times. Then the Americans with Disabilities Act (ADA) came into play. Wheelchair ramps and handicapped restrooms became commonplace in common spaces, and the result has been an improved quality of life for millions.
Then there’s the subject of home design. Homes have been modified for many years to meet the needs of the disabled, but now there is a new concept of “universal design,” which means homes being built for all needs from the beginning, even if there is not currently a disabled person living there.
“Along with aging in place, universal design is becoming more of a household term,” says T-Square Company (14141 Highway 290 West, Suite 800 in Austin) in is online blog. “Essentially, it’s about building or modifying places and spaces—both public and private—to accommodate people of all ages and abilities. More than just an architectural concept, universal design is a win-win for sandwich generation boomers caring for aging parents and their children at home, for grandparents raising grandchildren and great-grandchildren, and for all who are facing the challenges of caring for a loved one with Alzheimer’s or other chronic diseases. Whether your family needs the support now or down the road, universal design features are a good long-term investment for the home itself.”
The trend toward 'universal design' in homes
Tuesday, Jan 15, 2019 @ 3:57pm
By David Wilfong

Principles Of Universal Design



Tags: disability access contractor, accessible home remodeling for disabilities, accessible bathroom design specifications, professional remodeling contractor, accessible bathroom remodel, specialty construction in Austin, accessible homes, home access in Austin, universal design/build contractor, universal design vs. aging in place, universal design contractor, home accessibility, accessible design, accessible housing, handicap accessible housing, handicap accessible house plans, accessible homes in austin, universal design techniques, Austin home remodeling for disabled, accessible home modifications, handicap accessible floor plans, accessible home builder in Austin, wheelchair accessible homes, special needs contractor, universal home design in Austin

Handicap Accessible Floor Plans

Posted byDavid L. Traut, CAPS on Mon, Oct 14, 2019 @ 13:10 PM

     T- Square Company in Austin, Texas is an industry leading accessible, universal, certified Aging in Place and VA approved Specially Adapted Housing custom home builder and remodeler. We offer both new totally accessible homes and complete handicap modifications for existing homes. Traditional home builders and remodelers don't really consider the needs of the disabled or elderly like ADA vanities , roll in showers, or specially adapted kitchens which are universal in nature.  It takes a special breed of contractor to realize special needs for special people.

Handicap Accessible Home Design In Austin

      A revolution in building design standards is long overdue.  Our current building design standards do not address the needs of more than one third of our existing population.  Many more people can greatly benefit from accessible design versus conventional design.  Our rapidly aging population is experiencing the limitations of our personal living environments.  Any evolution in building practically always begins in the common areas of the commercial building sector.  The American Disabilities Act of 1990 increased the attention needed for those people having the right to equally access their work place and any recreational or leisure facilities.  These rules at least offer minimal solutions for those needing the most help with any building access.  In Austin, we now must  provide access to one bathroom on the first floor in new homes as deemed by our newly adopted building regulations.  This basic right to a handicap accessible bathroom is finally being enforced by the city's building inspectors.  What a tremendous needed and basic design improvement!

     Finding the right design/build contractor with ADA knowledge and experience can be a challenge.  Obtaining help for maintaining your independence throughout an accessible wheelchair design in Austin is possible.  You should be looking for a CAPS certified contractor who understands life changes.  A local contractor who offers specialty products and services standing out from the rest of the pack.  A contractor who has the ability, through experience,  to help clear the murky water impeding your accessible route and how it can be accomplished.  One who takes ADA remodeling to another level promoting safety.  A well versed construction professional can take on and solve any residential ADA challenge creating handicap accessible house plans.  These can include widening doorways, ADA compliant kitchen cabinets, or ADA compatible baths

Home Accessibility Help

     Accessible floor plans can include level no step entries, wider hallways and doorways, adequate maneuvering space for a wheelchair turning radius throughout the home, non-slip flooring, ramps to overcome level changes, clear unobstructed walkways, special area lighting, accessible closets and storage, roll out or pull out shelving, easy grab door hardware, automatic and graspable faucets, full extension drawers, accessible switches and outlets, roll in showers, ADA roll under vanities, counter tops, and work spaces, accessible kitchen appliances, and many other specialty features designed around the homeowner's abilities.

     A handicap accessible house plan takes the special needs of the physically disabled into consideration throughout the entire design. This type of home layout typically includes fewer walls, more open space, and wider hallways for increased mobility throughout the home for those that require the use of a wheelchair.

     The Americans with Disabilities Act (ADA) ensures that public spaces are designed to accommodate disabled patrons, and this type of home does as well. After all, living with a disability presents many challenges, as the ADA acknowledges, and navigating the home shouldn't be one of them. The home shouldn't ever make the homeowner feel like a prisoner within it's walls.

    Aging in place construction and Austin ADA remodeling has become synonymous with handicap accessible home design and modification during our lifetime.   Home modifications can be used to accommodate anyone from people with mobility impairments to those with vision loss, hearing loss, or even cognitive or developmental disabilities. Accessibility home modifications or wheelchair accessible kitchen and bathroom remodeling in Austin will allow anyone with limited mobility within your home to feel more empowered and independent.  The extent of a customized accessibility design is dependent upon the activity level of the person requiring the modifications.

Handicap Accessibility

     Today's conventional building standards conflict with most people's accessibility when you consider our created architectural barriers concerning cabinetry and door opening widths, individual strength, range of motion, movement,  manual dexterity, balance, and coordination. Once the demands of our built environment exceed their capacities we become excluded from a room or even the entire home.  The building world must work in unison to be sure the entire living environment meets basic needs in addition to affordability and structural integrity for the consumer and home owner.  This includes both the home and the components within the home being accessible to all inhabitants.  Privacy, sense of belonging, sense of control, and the sense of safety and security make up the quality of life for any home and should be considered for any design increasing home accessibility.



Tags: barrier free remodeling, handicap remodeling, disability remodeling, handicap access bathroom remodel, ADA compliant wheelchair accessible showers, disability access contractor, home modifications for Austin veterans, veterans home accessibility help in Austin, Texas, ADA compliant roll in showers, wheelchair accessible shower stalls, accessible bathroom design specifications, specialty construction in Austin, what is ada compliant, home access, accessible homes, what is an ADA compliant bathroom, home access in Austin, bathroom remodeling contractors Austin, TX, bathroom remodel contractors, universal design/build contractor, universal design vs. aging in place, universal design contractor, home accessibility, accessible design, why universal design, what is universal design in Austin, what is aging in place, wheelchair accessible housing, accessible housing, handicap accessible housing, handicap accessible house plans, accessible homes in austin, universal design techniques, Austin home remodeling for disabled, accessibility home modifications, accessible home modifications, wheelchair accessible bathroom, handicap bathroom design, handicap bathroom requirements, handicap bathroom vanity, modifying your home for a disabled child, wheelchair access, handicap bathroom contractor in Austin, handicap accessible floor plans

Austin Home Remodeling For Disabled

Posted byDavid L. Traut, CAPS on Wed, Sep 04, 2019 @ 10:09 AM


     Our existing architecture does not lend itself well to accomplishing any easy aging in place home remodels in Austin.  In fact, there are more inaccessible homes in all of the US than there are accessible homes and 45% of these existing homes are owned by the baby boomers representing the oldest group of homeowners.  Generally speaking in most residential US properties there are no easy ways to enter into bathrooms or utilize  kitchens without coming into contact with one architectural  barrier or another-especially if a wheelchair or walker is being used to help with mobility issues.  While an estimated 80% of aging homeowners have a firm plan to age in place, everything requires the proper clearance and distance for a new customized accessible route in your home to function properly provided by wheelchair remodeling.

     The concept of successful aging has become increasingly important as senior citizens begin to dominate the population. An active engagement in life through participation in social and productive activities is one component of successful aging. The built environment directly impacts the engagement profiles of older adults so it is necessary to provide environments designed to suit the needs of aging adults. Of all the design theories that attempt to accommodate the aging process, universal design may be the most desirable option as it provides built environments that benefit everyone. Universal design is a promising voluntary philosophy that requires increased attention from designers and builders participating in aging in place. Taken as a whole, it is evident that the application of universal design to the built environment is a positive step toward successful aging.

Principles Of Universal Design

Certified Aging In Place Specialist

  But you say to yourself that  your needed aging in place home modifications basically require general home remodeling in Austin, Texas or in any other town for that matter.  Aging in place services provided by a specialized remodeling contractor holding a national CAPS certificate is who you need as a partner to insure that  the accessibility issues of your home are solved correctly.  With over 30 years of remodeling experience I obtained my registered CAPS certificate.  By offering a design/build firm to my aging in place customers, I get personal satisfaction from giving my clients their independence back while the remain in their existing home.  Without the training required to earn the CAPS certificate on top of my decades of building knowledge I could not offer my customers such a thorough and complete solution for solving their accessibility issues.  Only an experienced qualified remodeler holding a CAPS certificate has the qualifications to design an accessible route and perform the construction required to make it safe and functional for the Aging In Place customer.  There is nothing more rewarding than seeing a person with mobility impairments be able to independently roll into his or her shower and be a part of that accomplishment.

Download Our Free Aging In Place Remodeling Considerations Checklist

  Let's compare the alternative costs associated with aging in place verses when you already own your home.   The more institutional alternative of assisted living accompanied by more medical expertise and staff training plus the access to emergency medical facilities is available as opposed to renting an apartment.  These are two of the main alternative choices for seniors who decide not to remain in their own homes.   According to a national study done in 2014, the average cost for assisted living ranged from $3,000 to $3,500 per month.  However, if you decide to age in place in a high quality one bedroom apartment, the rent will run around $1,300 per month.  Seniors living in their own home or with loved ones represents a preference by most seniors and property taxes must be taken in account.

     An average Aging in Place bathroom home modification providing total accessibility given there is a large space to remodel at onset will come in around $30,000.  This can vary in many aspects if there is not enough room to change the existing floor plan.  Smaller bathrooms can cost $15-20,000 but will not have the barrier free accessibility as the larger modified bathroom.  Fully accessible kitchens will run on the average of $50,000 depending on the size of the existing kitchen.  These are both one time costs for sustainability of a given lifestyle and location providing future independence and safety for the homeowner who participates in accessible home remodeling.  A wheelchair accessible roll in shower alone can cost $15,000 depending on the given plumbing situation and the size required for maneuverability. Many aging homeowners are more than willing to accept these costs if the modifications will give them the freedom to age in place.

     There are five criteria which must be modified in a home to provide a highway for aging in place.

Widen Doorways

If a senior relies on mobility aids, such as a walker or wheelchair, to navigate through her home, widening doorways is a must-have home modification. Depending on the insulation and placement of electrical switches and outlets in the home, costs vary greatly for widening doorways.

Install Ramps

Exterior stairs may be a challenge for seniors who are unsteady on stairs or who have balance issues, so installing ramps is a necessary home modification that is well worth the cost to provide greater independence. CAPS certified contractors are trained in building and installing ramps of the correct height and slope for seniors.

Indoor threshold ramps are also necessary home modifications for older adults who use wheelchairs. These indoor ramps provide smooth transitions from one surface to another, making it safer to navigate throughout the home. The threshold ramps often are constructed of rubber, so they’re easily adjustable to accommodate the step or door jamb height that is involved in the transition.

Kitchen Modifications

As seniors age, they may find that their appliances are no longer in ideal locations and that their counter tops and cabinetry are too high, especially if they are in a wheelchair. Every appliance must be placed within the reach distance for a seated person between 18 and 48 inches.  Professional Caps certified contractors may need to come in and adjust the counter height and lower the sink, to allow for easier access from a seated position. Additionally, seniors aging in place often find it easier when microwaves are placed in microwave stands, as opposed to being at the back of the counter or in raised microwave cabinets.  Providing multi-level counter tops is a way to give accessibility to everyone in the kitchen.

Shower and Bathtub Modifications

A senior opting to age in place also should consider home modifications for the bathroom, particularly the bathtub. One option is a bathtub to shower conversion, which provides a much easier and safer entry and exit than a bathtub. A second bathroom modification option is to replace a traditional bathtub with a walk-in tub.

Roll in showers without curbs are advised for everyone on a universal level for an accessible bath.  A 5 feet square clear floor space is an optimum size when a caretaker is involved. Using a 32-36"  wide barrier free entrance in a shower partition with an out-swinging door is advised for everyone.  Remember wider is better in all respects. Upon exiting the shower a clear floor space of 30"x48" for approach to the shower should be present and this area intersects with a five feet turning radius within the room. The shower should contain a shower wand on a sliding bar mounted at 48" above the floor to be available for varying heights of use accompanied by a regular height fixed shower head above.  These diverse shower heads are both regulated using a diverting controller valve.  Always use a shower valve that is thermostatically controlled and pressure-balanced to prevent scalds. If you desire a full body wash, you can include a regular shower head as well. Installing fixtures with a scald guard or lowering the temperature at the water heater is a must to prevent burns. Fold down seats attached to the shower wall are useful if caretakers are involved. Recessed shampoo niches are helpful to eliminate clutter on the shower floor.  Secure grab bars installed on wood grounds buried within the walls around the entire shower perimeter installed at 34-36" above the finished shower floor increases the safety factor and helps to prevent falls.  A recessed can light fixture should be installed above the shower area for proper lighting. All of the bathroom floor surface must be nonskid type to prevent slipping on a guaranteed wet floor. The ultimate goal in accessible design is to make the bathroom space safe for everyone who uses the bathroom. Universal design can better accommodate wheelchair users and can make the bathroom more comfortable for all users and many times can be done without sacrificing style. It is important to carefully plan the building or remodeling for a wheelchair accessible bathroom by taking inventory of the users capabilities and preferences.

If a senior wants to keep his existing bathtub, or cannot afford to replace it, there are less expensive modifications that can be made to prevent slips and falls in the bathtub. One modification is to add a grab bar to the tub, while another is to install safety strips. Both of these simple modifications can help prevent slips and falls in the bathtub.

Yet another modification for the bathtub, which is less expensive than replacing the bathtub or shower, is to purchase a bathtub transfer bench. Transfer benches straddle the side of the bathtub, enabling seniors to sit safely on the bench while getting into the tub by lifting each leg, one at a time, over the bathtub wall. Getting into the tub while seated greatly reduces the risk of dangerous slips and falls for seniors. Some seniors who cannot spare the required bathroom floor space for bathtub transfer bench legs opt for bathtub chairs, which sit completely inside the bathtub. Seniors may be able to turn around and sit on the chair with both legs outside of the tub and then lift one leg at a time over the tub wall while seated.

Flooring Modifications

Flooring is another consideration for older adults making home modifications with the goal of aging in place. The first step is to evaluate the home’s existing floors. If the carpet is older and shaggy, you may want to consider replacing it with new carpeting that has a shorter nap. Seniors are less likely to trip on shorter-nap carpeting, and it’s also more suitable for seniors who navigate through the home with the use of a walker or wheelchair.

Hardwood, tile, laminate, and vinyl floors are smooth and may allow for easier wheelchair maneuvering, but they also tend to be more slippery than carpeting. People often use throw rugs on these types of flooring, so be sure that you either get rid of them or securely tape them down to prevent trips and falls.  Using the proper tile with an acceptable coefficient of friction will prevent slipping even when wet.

     The best way to prepare for aging in place is to have a definite plan considering all possible outcomes and needs for those involved.  Aging in place isn't for everyone like those with major health issues.  For others with more independence, it can be a practical decision providing quality of life and safety for many years.  Everyone's needs are different as we age and one must allow for flexibility and change for all future decisions.

     The best course of action to take when making home modifications for seniors aging in place is to consider all of the areas of the home that present the most trouble or concern. If there are things that are especially difficult for seniors, like reaching the counter tops or light switches, modify them. If there are potential tripping or falling hazards, eliminate them or modify them accordingly. Taking a proactive approach to modifying the home means that seniors can age in place independently while their loved ones have peace of mind knowing that their aging loved ones are safer in their homes.

      Construction and design professionals are taking advantage of the CAPS training across the nation. This designation is taught through the National Association of Home Builders in collaboration with AARP. CAPS connects responsible professionals with home owners who need these services on an ever increasing basis. CAPS is a nationwide initiative and all active CAPS professionals can be found at nahb.org/CAPSdirectory.  David L. Traut, CAPS the owner of T-Square Company in Austin, Texas is one of the select group of professionals nationwide to earn the Certified Aging-In-Place Specialist (CAPS) designation, identifying him as a home remodeler and builder with the skills and knowledge necessary to remodel or modify a home to meet the unique needs of the older population, disabled owners, or their visitors.

 ACCESSIBLE BATHROOM WITH WHEELCHAIR ACCESS


Happy Trail AIP 016.jpg


 Aging In Place Home Modifications

Wheelchair Accessible Remodeling

Tags: kitchen remodeling, kitchen makeovers, ADA accessible, accessible routes, aging in place, wheelchair accessible remodeling, wheelchair accessible baths and kitchens, handicap home modifications, bathroom remodels, bathroom makeovers, CAPS certification, ADA remodeling, ADA compliance, aging in place remodels, home remodeling for disabled, home remodeling for disabled in Austin Texas, disability contractor in Austin, special needs contractor in Austin, disability and special needs contractor Austin, home modifications for elderly in Austin, bathrooms with disability access in Austin, Texas, Austin disability contractors for special needs, Austin handicap bathroom contractor, handicap accessible remodeling, barrier free remodeling, handicap remodeling, handicap accessible bathroom remodeling, handicap accessible home renovations, handicap accessible home modifications, disability remodeling, handicap accessible bathroom remodel, Austin aging in place specialist, handicap access bathroom remodel, handicap accessible bathroom shower, handicap bathroom remodel, ADA compliant wheelchair accessible showers, roll in shower design for wheelchair access, disability access contractor, bathroom remodeling contractors Austin, TX, bathroom remodel contractors near me, universal design/build contractor, universal design vs. aging in place, accessible design, what is universal design in Austin, what is aging in place, wheelchair accessible housing, handicap accessible house plans, Austin home remodeling for disabled

What Is Aging In Place

Posted byDavid L. Traut, CAPS on Tue, Aug 27, 2019 @ 14:08 PM

     Regardless of your age, you may want to recognize and take under advisement some universal design techniques for your next new construction or home remodeling project. Some people confuse aging in place with universal design.  Both are a method to increase accessibility within the home but aging in place strictly deals with an existing home. Aging in place design also implies modifying any home for it's older occupants to insure that the inhabitants can safely remain there as long as they possibly can through elder living solutions.  This time will expire once they need assisting medically trained help for safeguarding their personal safety in a nursing home or an assisted living environment.  Universal design is just that; offering choices to all of a home's residents no matter their age or physical capabilities.  It starts with a design and then the construction begins. When universal design ideas are incorporated into their floor plan, homes can accommodate the needs of their owners as those needs evolve over time.  Better yet, at time of resale your home will be available to a much larger market of consumers.

Certified Aging In Place Specialist

Aging In Place Living Area In Austin

     There are really three categories of aging in place customers requiring home modifications.  Those who are simply and wisely planning ahead for their futures to remain in their present homes.  The second category concerns those people who know they have a chronic medical disorder and need to prepare in advance for accessibility issues which will come as a result of their disease.  People with diseases that are constantly causing increased physical or mental changes to their being are a good representative of this second group.  The third group involves those people who either have had a chronic problem that has  progressed severely altering their mobility or those who have sustained a life altering tragedy such as being involved in an accident.  All of these groups will drive the future metamorphosis of existing inaccessible dwellings.

Principles Of Universal Design

Elder Construction

      Each individual with similar impairments describes his or her limitations differently when undergoing elder construction.  The blind don't experience their world the same as a person with deafness.  The checklist below contains features you may want to consider for your next new construction or renovation project. It also provides a quick reference for various aging in place issues. Because this list is not comprehensive due to people's differing needs, it’s best to also consult with a Certified Aging In Place Specialist. To find one in your area, go to nahb.org/capsdirectory

Download Our Free Aging In Place Remodeling Considerations Checklist



Aging In Place Designs

The interior floor plan

A single story one level living area without steps between living areas or attached rooms

A 5-foot by 5-foot clear/turn space in living area, kitchen, a bedroom, and one bathroom

A clear hallway of at least 36" in width being well lit providing an accessible barrier free route of travel throughout the home

All thresholds and transitions along the clear floor space should be tapered and no more than 1/2" in height

All doors should be minimally 36" wide along the accessible route producing a 32" clear opening. All doors should have lever hardware

Kitchen and laundry

Wall support and provision for adjustable and/or varied height counters and removable base cabinets

Upper wall cabinetry three inches lower than conventional height

Accented stripes on edge of counter tops to provide visual orientation to the work space

Counter space for dish landing adjacent to or opposite all appliances

Base cabinet with roll out trays and lazy Susans

Pull-down shelving

Glass-front cabinet doors

Open shelving for easy access to frequently used items

Appliances

Easy to read controls located at front

Washing machine and dryer raised 12-15 inches above floor

Front loading laundry machines

Microwave oven at counter height or below

Side-by-side refrigerator/freezer

Side-swing or wall oven

Raised dishwasher with push-button controls

Electric cook top with level burners for safety in transferring between the burners, front controls and downdraft feature to pull heat away from user; light to indicate when surface is hot

Miscellaneous

A 30-inch by 48-inch clear space at appliances or 60-inch diameter clear space for turns

Multi-level work areas to accommodate cooks of different heights

Open under-counter seated work areas

Placement of task lighting in appropriate work areas

Loop handles for easy grip and pull

Pull-out spray faucet; levered handles

Bathroom

Wall support and provision for adjustable and/or varied height counters and removable base cabinets

Contrasting color edge border at counter tops

At least one wheelchair maneuverable bath on main level with 60-inch turning radius or acceptable T-turn space and 36-inch by 36-inch or 30-inch by 48-inch clear space

Bracing in walls around tub, shower, shower seat, and toilet for installation of grab bars to support 250-300 pounds

If stand-up shower is used in main bath, it is curbless and minimum of 36-inches wide or for any custom tub shower conversions

Bathtub - lower for easier access

Fold down seat in the shower

Adjustable/handheld shower heads, 6-foot hose

Tub/shower controls offset from center and below 48"

Low profile shower stall with built-in antibacterial protection

Light over shower stall

Comfort height toilet two and half inches higher than standard toilet (17-19 inches) or height-adjustable

Design of the toilet paper holder allows rolls to be changed with one hand

Wall-hung sink with knee space and panel or insulation to protect user from scalding pipes

Slip-resistant flooring in bathroom and shower

Electrical, lighting, safety, and security

Light switches by each entrance to halls and rooms

Light receptacles with at least two bulbs in vital places (exits, bathroom)

Light switches, thermostats, electrical panels and other environmental controls placed in accessible locations no higher than 48 inches from floor

Electrical outlets 18-inches above the floor and may need to be closer than 10-feet apart

Clear access space of 30-inches by 48-inches in front of switches and controls

Rocker or touch light switches

Easy-to-see and read thermostats set at or below 48"

Programmable thermostats

Home wired for security

Other ideas

Separate apartment for rental income or future caregiver

Flex room that can used as a nursery or playroom when the children are young and as a home office later; if combined with a full bath, room could also be used for an aging parent/aging in place

     Let's face it, accessible homes are needed by all of us at some time in our lives.  This is true whether it's for ourselves, a family member, or a guest.  The need is certainly not driven by age but is a result of life's experience sometimes requiring wheelchair remodeling.  Any family living with disability among any of it's generations within it's group can always benefit from additional home accessibility.   This will in turn increase safety and independence for all involved as they go through life.

     The National Association of Home Builders, in partnership with the AARP and Home Innovation Research Labs, created the CAPS program, which includes training and education on the technical, business management and customer service skills essential to compete in the fastest growing segment of the residential remodeling industry--home modifications for aging in place.  David L. Traut, CAPS owner of T-Square Company in Austin, Texas is one of the select group of professionals nationwide to earn the Certified Aging-In-Place Specialist (CAPS) designation, identifying him as a home remodeler and builder with the skills and knowledge necessary to remodel or modify a home to meet the unique needs of the older population, disabled owners or their visitors.

     For additional information about the CAPS program, visit nahb.org/CAPS.  For more information about T-Square Company, visit www.tsquareco.com or call 512-444-0097.

Aging In Place Home Modifications

Tags: aging in place remodeling, aging in place home modifications, aging in place, aging in place home improvements in Austin, wheelchair accessible baths and kitchens, handicap home modifications, ADA remodeling, aging in place construction, aging in place designs, accessibility home remodeling in Austin, aging in place services, aging in place design,, certified aging in place specialist, Austin elder construction, handicap home modifications for disabled, handicap accessibility, handicap remodeling contractors, bathroom modifications for disabled, home modifications Austin, Texas, ADA bathroom Austin, Texas, wheelchair accessible showers in Austin,, roll in showers, accessibility designs Austin Texas, handicap bathrooms, home modifications for independent living Austin, universal design/build ideas, home modifications for elderly in Austin, Austin handicap bathroom contractor, barrier free remodeling, handicap remodeling, disability access contractor, accessible home remodeling for disabilities, professional remodeler, home remodeling contractors residential, disabled bathroom remodel, accessible bathroom remodel, specialty construction in Austin, home remodeling contractor residential, professional construction services in Austin, what is ada compliant, accessible homes, accessible design, what is aging in place, accessible housing, accessible homes in austin

Handicap Accessible House Plans

Posted byDavid L. Traut, CAPS on Tue, Aug 27, 2019 @ 11:08 AM

     Finding the right design/build contractor with ADA knowledge and experience can be a challenge.  Obtaining help for maintaining your independence throughout an accessible wheelchair design in Austin is possible.  You should be looking for a CAPS certified contractor who understands life changes.  A local contractor who offers specialty products and services standing out from the rest of the pack.  A contractor who has the ability, through experience,  to help clear the murky water impeding your accessible route and how it can be accomplished.  One who takes ADA remodeling to another level promoting safety.  A well versed construction professional can take on and solve any residential ADA challenge creating handicap accessible house plans.  These can include widening doorways, ADA compliant kitchen cabinets, or ADA compatible baths

Certified Aging In Place Specialist

     Concerning home accessibility, door widening is a common problem especially where wheelchair access is a must.  All doors should be 36" wide with the correct locking hardware installed.  The rule is 32" clear within the accessible route but 32" doors don't give enough clearance because of their stops.  You also need to pay attention to which side the lockset is installed on to not limit any wheelchair access or operation of the door's locking hardware.

     ADA compliant kitchen cabinets give you the ability to freely roll under the correct depth sink with covered or insulated water and drain lines.  The sink should be equipped with a proper automatic or wrist handle faucet.  A finished cabinet top height of 34" will also be observed.  Wall cabinets should be mounted around 4" lower than usual for reachability from a sitting position.  An unobstructed five feet turning radius on the floor should also be maintained.

ADA Kitchen Cabinetry

     Bathroom transformations complying with ADA revisions also require the same turning radius noted in the kitchen along with a correct bathing facility.  If a tub is useful, correctly placed grab bars must be installed for safety reasons.  Showers can be either the roll in or transfer type dictated by the individual user's physical abilities.  The comfort height toilet should have grab bars installed at 34" on the side wall as well as at the rear at a minimum.  The flush handle should be oriented toward the middle of the room away from the side wall.  The bathroom sink should be accessible as in the kitchen mentioned above.

A Correct Kitchen Sink With Adequate Knee Clearance in The Accessible Route

ADA Kitchen In Austin

     Traditional home builders and remodelers don't really consider the needs of the disabled or elderly like ADA vanities or roll in showers which are universal in nature.  It takes a special breed of contractor to realize special needs for special people.

     A revolution in building design standards is long overdue.  Our current building design standards do not address the needs of more than one third of our existing population.  Many more people can greatly benefit from accessible design versus conventional design.  Our rapidly aging population is experiencing the limitations of our personal living environments.  Any evolution in building practically always begins in the common areas of the commercial building sector.  The American Disabilities Act of 1990 increased the attention needed for those people having the right to equally access their work place and any recreational or leisure facilities.  These rules at least offer minimal solutions for those needing the most help with any building access.  In Austin, we now must  provide access to one bathroom on the first floor in new homes as deemed by our newly adopted building regulations.  This basic right to a handicap accessible bathroom is finally being enforced by the city's building inspectors.  What a tremendous needed and basic design improvement!

Home Accessibility Help

    Aging in place construction and Austin ADA remodeling has become synonymous with handicap accessible home design and modification during our lifetime.   Home modifications can be used to accommodate anyone from people with mobility impairments to those with vision loss, hearing loss, or even cognitive or developmental disabilities. Accessibility home modifications or wheelchair accessible kitchen and bathroom remodeling in Austin will allow anyone with limited mobility within your home to feel more empowered and independent.  The extent of a customized accessibility design is dependent upon the activity level of the person requiring the modifications.

     Aging in place home modifications are available through T-Square Company in the Austin area. We have an A plus rating with the local BBB and have over 30 years of remodeling experience. We are additionally a certified aging in place specialist offering complete aging in place services.  Each design/build situation will be customized to fit your personal needs increasing your accessibility. Call 512-444-0097 today to begin the accessible second chapter of your life while remaining safe and secure in your existing home. CAPS #1636580

Tags: Texas, kitchen remodeling, how-to, ADA compliant kitchen cabinets, ADA accessible, accessible routes, ADA bathroom cabinets accessible routes, wheelchair accessible remodeling, wheelchair accessible baths and kitchens, ADA remodeling, ADA bathroom cabinets, accessibility home remodeling in Austin, accessible home remodeling, Austin bathroom remodel, home modifications for independent living, handicap remodeling contractors in Austin, remodel bathroom for handicap Austin Texas, handicap home modifications for disabled, handicap remodeling contractors, home modifications Austin, Texas, ADA remodeling Austin, Texas, ADA bathroom Austin, Texas, age in place home design, home remodeling for disabled, wheelchair accessible home remodeling in Austin, remodeling for elders in Austin, disability contractor in Austin, disability and special needs contractor Austin, handicap accessible remodeling, handicap remodeling, disability remodeling, roll in shower design for wheelchair access, disability access contractor, ADA compliant roll in showers, roll in shower, accessible toilets, handicap accessible toilets, home remodeling professional, specialty construction in Austin, home access, accessible homes, Austin bathtub to shower conversions, Austin tub conversions, bathroom remodeling contractors Austin, TX, bathroom remodel contractors, universal design/build contractor, home accessibility, wheelchair accessible housing, accessible housing, handicap accessible housing, handicap accessible house plans

Bathtub Remodeling Near You

Posted byDavid L. Traut, CAPS on Fri, Aug 23, 2019 @ 12:08 PM

     Even if you only use your tub to wash the dog or wash your mini-blinds, most real estate agents are adamant about having at least one bathtub in your house to preserve marketability. A recent Houzz poll agrees, with 58% of respondents claiming, "you'll never sell that house without a tub." However, bathtub to shower conversions are very popular for many households. Whether you are looking for a safer alternative to climbing over a tall bathtub wall or simply want to create a more sophisticated style in your bathroom many designs are available without extensive remodeling.

     If your current bathroom is unsafe or if you find it inconvenient you may need to consider a complete bathroom remodel. Then you can build in ease of use, and you can add safety features that address slips and falls, and other concerns as you age. This is especially important if you live alone. A fall in the shower or the bathroom can be a devastating and frightening experience. Sometimes it's possible to address these problems by making significant changes. These can include options like adding a monitored alarm system to alert people to a fall or removing the bathtub and installing a large, low or zero threshold shower with slip resistant porcelain floor tiles.

Bathroom Remodel Austin, Texas

Tub To Shower Conversions

     If your old tub is in an alcove, you can remove it and be left with a space that's about 30 to 34 inches deep and 5 feet wide. This is an adequate space for a shower. With some minor modifications, your water supply and drain lines will already be in place, saving you money on plumbing costs. With some limited framing alterations, you can enjoy future shampoo niches, folding seats, and grab bar placement. The floor of your shower has a lot to do with the style and cost of your tub to shower remodel. You have a choice of two basic types of pan: one contains water with curbs that you step over as you enter while the other recessed type is curbless. Liners or pans beneath the floor tile can be composed of either a custom fiberglass application or the proper vinyl material. Waterproofing is the most important aspect of shower building and all precautions must be taken.  One piece above the slab shower bases can solve any future problems that might arise using any type of shower pan.  These can be equipped with add on ramps for wheelchair access if the floor slab construction will not allow lowering the shower floor for roll in capability. Prefab fiberglass sides are the cheapest way to complete the shower; but, a custom tiled unit will have better resale value even though it is more costly.

     If you're a homeowner and contemplating aging in place the main area you'll need to consider is the bathroom. Accessible showers should be a part of any aging in place bathroom remodeling project. Even if your middle aged and planning for the future, an accessible shower is a smart investment because they can be built to be usable by anyone including those in a wheelchair. These showers are designed to provide for a person's safety in the shower by utilizing design elements like no or zero step entries, grab bars, non-slip flooring and more. A properly and fully designed bathroom will incorporate these and other features. This is called Universal Design, and the principal includes accessibility, hardware, and materials. This building technique works to help create a safe showering experience for people of all abilities and ages. If you're planning a bathroom remodel to aging in place, it is a different type of remodeling than one undertaken for merely aesthetic purposes. That's not to say that aging in place bathroom remodeling can't be aesthetically beautiful. It simply means that the choices you make will incorporate safety and independence for aging homeowners along with ease of use. For older homeowners, a walk in or low threshold shower is a smart choice. Both the lower threshold and the shower entry width are mutually important for accessibility. This will allow those using any mobile device like a wheelchair or walker to safely enter the shower.

     Certainly there are many upgrades available when planning a bathroom transformation.  A custom tub shower conversion for the replacement of the tub with a new walk in or roll in shower can create a bold  look but will run you around $13,000.  There are no spending limits for bathroom remodels.   You can plan on spending around $12,000 to $15,000 for a hall bath remodel.  The price tag can approach or exceed $35,000 for a complete master suite remodel.  The type of fixtures and building components chosen along with the labor will compose the overall cost of the remodeling project.

Bathroom Remodeling Austin

     The fastest growing segment of the residential remodeling industry is home modifications for aging in place and ADA accessibility. David L. Traut, CAPS the owner of T-Square Company in Austin, Texas is one of the select group of professionals nationwide to earn the Certified Aging-In-Place Specialist (CAPS) designation, identifying him as a home remodeler and builder with the skills and knowledge necessary to remodel or modify a home to meet the unique needs of the older population, disabled owners, or their visitors.

     We here at T-Square Company know that quality and customer service has always been at the heart of our mission. We often go above and beyond making sure your new shower meets all your requirements for luxury, style, functionality, and safety. To get the process of replacing your old tub with a beautiful new shower started today, just give us a call at 512-444-0097 or fill out one of our online contact forms to request a free no obligation consultation.  We offer a complete design/build service to our customers.

Tags: accessible home remodeling, Universal Design,, Austin bath remodeling, Austin bathroom remodeling, Austin bathroom remodel, aging in place specialist, certified aging in place specialist, handicap remodeling contractors in Austin, bathroom renovations in Austin, Texas, bathroom remodeling contractor Austin Texas, bathroom remodeling Austin Texas, bathroom upgrades Austin, remodel bathroom for handicap Austin Texas, disability home modifications, bathroom accessibility remodels in Austin, disability access contractor, accessible home remodeling for disabilities, barrier free showers in Austin, handicap ADA roll in shower, roll in shower, home remodeling near me, home remodeling professional, home remodeling contractors residential, disabled bathroom remodel, accessible bathroom remodel, professional construction services in Austin, home access, home access in Austin, Austin bathtub to shower conversions, Austin shower remodel, Austin shower conversions, Austin tub conversions, bathroom remodeling contractors Austin, TX, bathroom remodel contractors, bathroom remodel contractors near me, bathroom remodel contractor

Home Access In Austin

Posted byDavid L. Traut, CAPS on Fri, Jul 12, 2019 @ 14:07 PM

     When mobility becomes an issue for any homeowner, regardless of age, the question arises concerning physically moving to a different home with a bath that is more accessible. Preparing for one of those highly likely events involving someone in your home needing room modifications for even a short time while recovering from surgery is surely a smart move. Solving aging in place issues will soon become the number one challenge concerning the present obsolete housing inventory in our country. Our present day obsolete homes now inhabited by the baby boomer generation will slowly and increasingly raise their outdated and obsolete ugly heads and expose their true lack of kitchen or bathroom accessibility to those very people inhabiting them. The situation will only become ever more expanding in time. When these homes were previously purchased, they represented an absolute castle in the world of their owners in which to prepare for a day and they also acted as a retreat from life's tough interactions. They housed our families, our memories, and our stuff. They represented a place where we could be ourselves. Our homes have always been exempt from any and all of the accessibility regulations that have been put in place since 1968 when our Viet Nam veterans were returning home.

ADA Accessible Bathroom In Austin

     The new evolving concept known as Universal Design and specialized handicap remodeling contractors for home access remodeling is catching on nation wide and has been for several years as a sign of the times. Universal design techniques used in building makes a home more accessible to all regardless of their mobility or adaptive abilities. An evolution of new products used for disability home modifications is making those homes more accessible and has finally come about in the remodeling industry. These new advances in accessible home remodeling in Austin not only keep the living environments safer but will not compromise the home's aesthetics. In fact, there are many benefits to using universal design techniques, including potential use by aging family members, added resale value, and the fact that you'll be creating a space that can be used by anyone who visits your home, regardless of their range of abilities. Simple universal design updates for aging in place home modifications and handicap bathroom accessibility can include adding grab bars or handrails throughout the home, adding a seat within the roll in shower, lowering upper cabinets and counter tops, adding non-slip flooring, widening hallways or installing stair lifts, and widening doors. Many people find themselves needing accessible homes for themselves or family members. There are approximately 30 million Americans using wheelchairs and the number of people who need accessible homes will continue to increase as disabled and aging people are finding more ways to remain living in their homes. One important way to increase independent living is making a home accessible to an individuals personal needs. Home modifications can increase safety, accessibility, and independence for people who want to live independently.

Handicap Accessibility

     The National Association of Home Builders, in partnership with the AARP and Home Innovation Research Labs, created the CAPS program, which includes training and education on the technical, business management and customer service skills essential to compete in the fastest growing segment of the residential remodeling industry--home modifications for aging in place and ADA accessibility in Austin, Texas. David L. Traut, CAPS the owner of T-Square Company in Austin, Texas is one of the select group of professionals nationwide to earn the Certified Aging-In-Place Specialist (CAPS) designation, identifying him as a home remodeler and builder with the skills and knowledge necessary to remodel or modify a home to meet the unique needs of the older population, disabled owners, or their visitors.

If you ever find yourself needing better accessibility within your home during a recuperation or as a general more permanent need please don't hesitate to reach out to me directly.

Sincerely,

David

Certified Aging In Place Specialist

Tags: residential general contractor Austin, Texas, home accessibility help in Austin, home remodeling for disabled in Austin Texas, wheelchair accessible home remodeling in Austin, universal design remodeling contractor, principles of universal design, Austin Senior Home Remodeling, disability contractor in Austin, disability and special needs contractor Austin, home modifications for elderly in Austin, bathrooms with disability access in Austin, Texas, Austin disability contractors for special needs, Austin handicap bathroom contractor, handicap accessible remodeling, handicap remodeling, handicap accessible home renovations, disability remodeling, handicap accessible bathroom remodel, handicap accessible bathroom shower, ADA compliant wheelchair accessible showers, disability access contractor, home modifications for Austin veterans, veterans home accessibility help in Austin, Texas, ADA compliant roll in showers, wheelchair accessible shower stalls, accessible bathroom design specifications, accessible toilets, barrier free toilets, ADA vanity height, ADA Compliant grab bars, professional remodeling contractor, professional remodeler, disabled bathroom remodel, accessible bathroom remodel, specialty construction in Austin, home remodeling contractor residential, home access, accessible homes, what is an ADA compliant bathroom, home access in Austin

Wheelchair Ramp Slope

Posted byDavid L. Traut, CAPS on Mon, Jun 24, 2019 @ 10:06 AM

DETERMINING SLOPE RATIO

     To determine the slope of your ramp and how much horizontal space it will require, use the following calculation per the ADA guidelines: Multiply the inches your ramp will rise by the slope ratio you desire, and then divide the sum by 12 (to convert the horizontal space you'll need to feet). For example: 31-inch rise x 20 slope ratio = 620. That divided by 12 gives you a 51-foot horizontal projection.

ADA wheelchair ramp guidelines are as follows:

  • The minimum ramp width must be 36 inches minimum but 48 inches is preferable.
  • Ramps must have edge protection to keep anyone from slipping off their surface in the form of a raised outer curb or railing.
  • All wheelchair ramps must have level or flat unobstructed landings at the top and bottom of the rise being overcome that are 60 inches by 60 inches to provide a proper five foot wheelchair turning radius. The landing areas cannot have more than a 30 feet long ramp separating them. If the rise distance requires longer than a 30 foot run to overcome it then a series of landings can be used creating a switchback design.
  • Thirty six inch handrails are required on both sides of all ramps that rise steeper than 6 inches from the ground below.
  • All surfaces must be slip resistant and stable.

     A wheelchair ramp can be permanent, semi-permanent or portable providing wheelchair accessibility. Permanent ramps are designed to be bolted or otherwise attached in place. Semi-permanent ramps rest on top of the ground or concrete pad and are commonly used for the short term. Permanent and semi-permanent ramps are usually of aluminum, concrete or wood. Portable ramps are usually aluminum and typically fold for ease of transport. Portable ramps are primarily intended for home and building use but can also be used with vans to load an unoccupied mobility device or to load an occupied mobility device when both the device and the passenger are easy to handle. Ramps can be constructed from a variety of different materials, though some are better than others and friction is of upmost importance.

     A wheelchair ramp is basically an inclined plane installed in addition to or instead of stairs. Ramps provide wheelchair users or users of other mobility aids as well as people pushing strollers,carts, or other wheeled objects, better access to any building. When designing a wheelchair ramp, you need to consider the users physical limitations. The ramp should be wide enough to be safe and maneuverable and sturdy enough to carry the weight of an electric wheelchair and it's cargo (this can approach 6-700 pounds in many instances) and have a slope that is gradual enough for a manual wheelchair user to navigate.

Austin Wheelchair Ramp

     The ADA guidelines recommend a slope ratio of 1:16 to 1:20. The Americans with Disabilities Guidelines dictate how ramps are designed for all public places. A noted 1:12 ratio is too steep for some people to navigate using a manual wheelchair. This translates into an 8% slope or grade. These ratios must be followed in all public places; however, there are no rules for residential construction. On a residential basis, the ramps can be customized for the user without having to rely on the ADA averages. The ADA rules become simply guidelines. The publication assists private homeowners to create ramps that are usable, safe and sturdy. Homeowners aren't required to follow these slope guidelines but if you have the available area then less slope is always better.

Home Accessibility Help

Many people find themselves needing accessible homes for themselves or family members. There are approximately 30 million Americans using wheelchairs and the number of people who need accessible homes will continue to increase as disabled and aging people are finding more ways to remain living in their homes. One important way to increase independent living is making a home accessible to an individuals personal needs. Home modifications can increase safety, accessibility, and independence for people who want to live independently.


Handicap Accessibility





    Whether your family needs the support now or down the road, universal design features are a good long-term investment for the home itself. Whatever your situation please remember to rely on the experiences of a local building professional.  Check out their credentials and references and don't limit yourself to only price checks against other bidders.  Don't make the mistake of letting a cabinet making subcontractor or tile installer play the part of a general contractor.  Their knowledge will be limited to that of the cabinets or tile and not much else.  More importance needs to be given to the reputable contractor's personality and knowledge and how well you two communicate.  You are making your choice for a professional to lead the way enabling your dream to be realized.  You get what you pay for with proper planning when using an experienced and qualified local contractor. T-Square Company is CAPS certified and can be reached at 512-444-0097 in Austin, Texas.  Find out how a design/build remodeling contractor can save you money during your next project.

Certified Aging In Place Specialist



Tags: aging in place designs, accessibility home remodeling in Austin, CAPS professional in Austin, CAPS certification holder in Austin, CAPS remodeling techniques, disability home remodeling in Austin, aging in place specialist, aging in place services, aging in place design,, elder construction, certified aging in place specialist, handicap home modifications for disabled, handicap accessibility, handicap remodeling contractors, disability home modifications, renovation contractor in Austin, texas, home modifications Austin, Texas, home improvements Austin,, residential remodeling contractor in Austin, accessibility remodelers in Austin, house remodeling Austin, home remodeling Austin, Texas, residential remodeling company in Austin, Texas, ADA remodeling Austin, Texas, accessibility designs Austin Texas, home modifications for independent living Austin, universal design/build, universal design/build ideas, Austin accessible home remodeling, certified aging in place consultant in Austin, aging in place design in Austin, age in place home design, home modifications for disabled children, what does it mean to age in place, universal design building for a lifetime, what is universal design, home remodeling contractor near Austin, Texas, residential general contractor Austin, Texas, remodeling companies in Austin TX, home accessibility help in Austin, home remodeling for disabled in Austin Texas, wheelchair accessible home remodeling in Austin, universal design remodeling techniques, why is universal design important, Universal Principles of design revised and updated, principles of universal design, home remodeling for seniors Austin, remodeling for elders in Austin, disability contractor in Austin, disability and special needs contractor Austin, home modifications for elderly in Austin, Austin disability contractors for special needs, handicap accessible remodeling, barrier free remodeling, handicap remodeling, handicap accessible home renovations, handicap accessible home modifications, disability remodeling, Austin aging in place specialist, disability access contractor, accessible home remodeling for disabilities, home modifications for Austin veterans, professional remodeling contractor, professional remodeler, home remodeling professional, home remodeling contractors residential, accessible bathroom remodel, specialty construction in Austin, what is ada compliant, home access, accessible homes, wheelchair ramp slope, wheelchair ramp specifications
